Filter for removal of iron, manganese, and water hardness OPM 20-72 - ECOMIX P

Code: AQC0001241 AQC000987 4843/60 4843/72 AQC000636 AQC000879 Choose variant
Not rated
€839,60 €1 039,60 €1 171,60 €1 687,60 €879,60 €915,60 from €839,60 €693,88 excl. VAT €859,17 excl. VAT €968,26 excl. VAT €1 394,71 excl. VAT €726,94 excl. VAT €756,69 excl. VAT from €693,88 excl. VAT
In stock; available within 1–3 days In stock; available within 1–3 days In stock; available within 1–3 days In stock; available within 1–3 days In stock In stock Choose variant
Amount of filling
Chosen variant is not available. Reset selected parameters.
Programming the control head

Filter for the removal of iron, manganese, and water hardness with a special filtration mix ECOMIX P. For use in households, small operations, and halls or smaller social facilities. Water temperature 2-38°C, for water flow up to 3.0 m³/h, operating pressure 1.38 - 8.61 bar. 3-year warranty.

Detailed information

Product detailed description

The OPM filter has a special filtration mixture ECOMIX P with a gravel bed (partially also acts as a sand filter) with a filtration efficiency of 85-90%. This filter is used for water with higher pH and in places where there are high levels of hardness, iron, and manganese. The filter's performance is set according to the input value of these elements (iron, manganese, and water hardness).

If your water shows higher content of iron, manganese, organic substances, or increased hardness and also has high pH, then the multifunctional OPM filter is an ideal choice for you. This series of filters contains the new filtering material Ecomix P.

Thanks to the use of the modern control unit PENTAIR Autotrol LOGIX MULTI 255/760, the filter has efficient and economical operation, which can be precisely tailored to the customer's needs and adjusted to the composition of the water. The filtering material Ecomix P is regenerated using ordinary tablet salt. Regeneration takes place according to the set flow rate and during the night hours (at 2 AM, lasting for 64 minutes), the assumption is regeneration every 4 days.

Extended warranty of 3 years.

made in europe

The filter is available in several sizes from 20 to 72 liters.

Technical specifications:

The product is certified and intended for contact with drinking water.

  • Head: PENTAIR Autotrol LOGIX MULTI 255/760
  • Head control: Volumetric (capacity) and/or time-based
  • Filtration material: Ecomix P
  • Operating pressure: 1.38 - 8.61 bar
  • Inlet and outlet connections: 1”, external thread
  • Waste connection: Plastic 1/2"
  • Operating temperatures: 2-38 °C
  • Built-in by-pass: Yes
  • External flange with main by-pass: Yes
  • Built-in water meter: Yes
  • Built-in flow meter: Yes
  • Overflow protection of the salt container: Yes
  • Electrical voltage: 230V / 50Hz
  • Max. hardness: 7.5 mmol/l
  • Max. iron concentration: 10 mg/l
  • Max. manganese concentration: 2 mg/l
  • Max. total mineralization: 4000 mg/l
  • Max. ammonium ions: up to 4 mg/l
  • COD-Mn: does not reduce
Name Tank diameter (mm) Total height (mm) Salt container diameter (mm) Salt container (liters) Tank (")
OPM 20 320 (width) 1130 - cabinet 9x35
OPM 24 320 (width) 1130 - cabinet 10x35
OPM 36 258 1550 320 75 10x54
OPM 48 310 1500 320 75 12x52
OPM 60 335 1550 540 150 13x54
OPM 72 360 1820 565 140 14x65



Name Connection Fill quantity (liters) Water consumption
(kg/1 reg.)
Salt consumption (kg/1 reg.) Nominal flow (m³/h) Maximum flow (m³/h)
OPM 20 1" 20 80 - 100 2.0 0.8 1.2
OPM 24 1" 24 100 -125 2.4 1.2 1.4
OPM 36 1" 36 140 - 175 3.6 1.3 1.5
OPM 48 1" 48 180 - 235 4.8 1.8 2.0
OPM 60 1" 60 240 - 300 6.0 2.2 2.4
OPM 72 1" 72 252 - 360 7.2 2.5 3.0
  • Before each OPM filter, a pre-filter for mechanical impurities must be installed.
  • Near the filtration, it is necessary to have a connection to the waste, where settled iron and manganese is discharged from the filtration.

Transport of the filtration equipment

We recommend sending the equipment on a pallet to avoid damage during transport. If you are purchasing regenerating salt together with the filtration equipment, you can add the pallet to your cart together with the salt.

Installation and service of the equipment

Installation and transportation will be provided by our own service technicians (we have 14 authorized service technicians across the Czech Republic and Slovakia). If you are interested, we will gladly create a price quote for you. The installation price depends on the complexity and materials used (connection hoses, valves, etc.). If you are interested in installation, please inform us in the notes in the cart ("Enter a note for the seller").

Service replacements are recommended to be done regularly once a year. The price for a service replacement is CZK 1,990 + travel expenses, which is paid flat rate CZK 590 (for Prague and Brno CZK 990) if the technician's trip is combined with other installations or service on the way.

Additional parameters

Category: Iron and manganese filters
According to the connection: On the water supply line
According to the type of filter: For hard water, For iron and manganese
According to the variant of water treatment: Economic option
According to undesirable substances: Water hardness, Iron, Manganese
According to usage: For households, For industry
By type: Multifunctional
Product type for water treatment: Water Softeners, Iron filters, Mangan filters
