Filtration set PX ECO TRIO

Code: AQC0001773 AQC0001774 Choose variant
Not rated
€55,20 €45,62 excl. VAT
In stock In stock Choose variant
Connection
Chosen variant is not available. Reset selected parameters.

PX ECO TRIO Filter Set combines three transparent plastic tubes with swivel nuts for inserting any filter cartridges of size 9“ ¾.  Connection ¾“ or 1“.

Detailed information

Product detailed description

PX ECO TRIO Filtration Set is a combination of three transparent plastic tubes for inserting any filter cartridges of size 9“ ¾. Choose between ¾“ or 1“ connections. By selecting the right filter cartridges, optimal quality of output water can be achieved.

The assembly is designed for effective water filtration in households and commercial operations. The design of individual filtration tubes consists of three main parts (head-nut-tube), which ensures easy installation and reliable operation. The tube is made of durable PET material, which guarantees long life and reliability.

The tube is equipped with a plastic vent valve and a 2 mm strip on the tube that helps properly center the head for easier installation and better pressure resistance. The star-shaped head design minimizes pressure losses. The smart placement of the key in the holder ensures it does not get lost. This model is compatible with various types of filter cartridges (DOE, BIG, COD3).

The filtration assembly is mounted directly on the water supply line (cold water inlet). The transparent body of the filter tube allows for easy visual inspection of filter cartridge contamination. This kit is primarily intended for mechanical filtration.

In combination with filter cartridges, the PX ECO TRIO filtration set forms a complete filter that removes all mechanical impurities (sand, dirt, clay, hair, and other insoluble particles) from the inlet water. Thus, it provides protection for appliances and assurance when using water for any purposes.

The packaging contains only empty filter tubes. Filter cartridges are not included!

Key Features:

  • 2 mm strip on the tube for easy installation and better pressure resistance
  • Reduced pressure loss due to the star-shaped head design
  • Compatible with filter cartridges: DOE, BIG, COD3
  • Smart placement of the key in the holder prevents loss

Technical Specifications:

  • Size: 9“ ¾
  • Connection: ¾“ or 1“
  • Materials: tube - polyethylene (PET), head - polypropylene (PP) with brass fittings
  • Mounting: threaded
  • O-ring: EPDM
  • Maximum operating pressure: 8 bar
  • Maximum operating temperature: from 5 °C to 50 °C
  • Mounting: horizontal
  • Connection: screw thread in inches

The product is certified and designed for contact with drinking water.

Dimensions (L×W×H×D):

  • 3/4" - 29.6 x 40.1 x 11.1 x 33 cm
  • 1" - 29.6 x 40.1 x 11.1 x 33 cm

Additional parameters

Category: Filters for mechanical impurities
According to the connection: On the water supply line
According to the type of filter: For mechanical impurities
