Mechanical filter cartridge DGD-7525 20" AB
Code: AQC0001700Related products
Product detailed description
Replacement filter cartridge for mechanical impurities filtration from water. Filtration fineness is 75 + 25 microns. Suitable for use with 20" AB type filters or with AQ TUBE filter 20“.
The filter cartridge is made from 100% polypropylene, and its porosity of 75 + 25 microns ensures high resistance to bacteria and viruses. Effective filtration guarantees the removal of mechanical impurities from water: sand, clay, dirt, hair, and other undissolved particles.
The design of the cartridges contains two layers of filter material. The outer layer is used for pre-filtration of the inner layer, which increases the capacity of these filter cartridges up to three times compared to standard cartridges.
The larger diameter of the cartridge reduces pressure loss and allows for operation at higher flow rates.
The effective filtration depth is increased by 233%, providing high filtration efficiency and a significantly longer lifespan of the filter cartridges.
Technical parameters:
The product is certified and intended for contact with drinking water.
- Material: polypropylene
- Cartridge length: 20"
- Size: AB, BB
- Micron rating: 75 + 25 microns
- Dimensions: 508 x 120 mm (20“ x 4.5“)
- Max. operating pressure: 8 bar
- Max. pressure differential: 0.8 bar
- Operating temperatures: 4-63 °C
- Cartridge efficiency: up to 95 %
Additional parameters
| Category: | Accessories for water filters |
|---|---|
| According to the type of filter: | Accessories |
| According to type and use: | Filtration cartridges |
| Filtration cartridges and refills: | Mechanical filters |
