PX ECO DUO filtration set

Code: AQC0001771 AQC0001772 Choose variant
Not rated
€39,20 €32,40 excl. VAT
In stock In stock Choose variant
Connection
Chosen variant is not available. Reset selected parameters.

Filter Set PX ECO DUO combines two transparent plastic tubes with threaded nuts for inserting any filter cartridges of size 9“ ¾.  Connection of ¾“ or 1“.

Detailed information

Product detailed description

PX ECO DUO Filtration Set is a combination of two transparent plastic tubes for inserting any filter cartridges of size 9“ ¾ . Available connections are ¾“ or 1“. By choosing the right filter cartridges, optimal quality of the output water can be achieved.

The assembly is designed for effective water filtration in households and commercial operations. The design of the individual filter tubes consists of three main parts (head-nut-tube), ensuring easy installation and reliable operation. The tube is made from durable PET material, which guarantees long life and reliability.

The tube is equipped with a plastic vent valve and a 2 mm band on the tube, which helps center the head correctly for easier installation and better pressure resistance. The star-shaped design of the head minimizes pressure losses. The smart placement of the key in the holder ensures that it does not get lost. This model is compatible with various types of filter cartridges (DOE, BIG, COD3).

The filtration assembly mounts directly to the water pipe (cold water supply). The transparent body of the filter tube allows for easy visual inspection of the filter cartridge's contamination. This set is primarily designed for mechanical filtration.

In combination with filter cartridges the PX ECO DUO filtration set forms a complete filter that removes all mechanical impurities from the input water (sand, dirt, clay, hair, and other insoluble particles). It thus ensures protection for appliances and peace of mind when using water for any purposes.

The package contains only empty filter tubes. Filter cartridges are not included!

Key features:

  • 2 mm band on the tube for easy installation and better pressure resistance
  • Lower pressure loss due to the star-shaped design of the head
  • Compatible with filter cartridges: DOE, BIG, COD3
  • Smart placement of the key in the holder prevents loss

Technical specifications:

  • Size: 9“ ¾
  • Connection: ¾“ or 1“
  • Materials: tube - polyethylene (PET), head - polypropylene (PP) with brass connection units
  • Mounting: threaded
  • O-ring: EPDM
  • Maximum operating pressure: 8 bar
  • Maximum operating temperature: from 5 °C to 50 °C
  • Mounting: horizontal
  • Connection: threaded in inches

The product is certified and intended for contact with drinking water.

Dimensions (L×W×H×D):

  • 3/4" - 29.6 x 26.3 x 11.1 x 33 cm
  • 1" - 30.1 x 26.3 x 11.1 x 33 cm

Additional parameters

Category: Filters for mechanical impurities
According to the connection: On the water supply line
According to the type of filter: For mechanical impurities
