Water pressure reducing valve with manometer 1/2"

Product detailed description

The pressure reducing valve for water supply is installed in cases of high pressure in the main water supply line or when there are significant pressure fluctuations.

It allows for the reduction and stabilization of water pressure and also prevents water hammer (a sudden change in pressure), which can damage connected devices.

Material used:

The reducers are made of brass and are suitable for drinking water.

Technical specifications:

• Connection diameter 1/2''
• Maximum inlet pressure - 16 bar
• Maximum temperature - 30°C
• Output pressure adjustment range - 1 - 6 bar
• Nominal flow rate - DN15 = 1.27 m3/h
• Factory setting - 3 bar
• Pressure gauge connection - G 1/4
