Water pressure reducing valve with pressure gauge 3/4"

Product detailed description

The pressure reducing valve for water supply is installed when there is high pressure in the main water line or during significant pressure fluctuations.

It allows for the reduction and stabilization of water pressure and also protects against water hammer (sudden pressure change), which can cause damage to connected devices.

Material used:

The reducers are made of brass and are suitable for drinking water.

Technical specifications:

• Connection diameter 3/4''
• Maximum input pressure - 16 bar
• Maximum temperature - 30°C
• Output pressure adjustment range - 1 - 6 bar
• Nominal volume flow - DN20 = 2.27 m3/h
• Factory setting - 3 bars
• Pressure gauge connection - G 1/4
