Water pressure reduction valve with pressure gauge 1"
Code: AQC0001433Product detailed description
The pressure reducing valve for water supply is installed in cases of high pressure in the main water line or when there are significant pressure fluctuations.
It allows for reducing and stabilizing water pressure and also protects against water hammer (sudden pressure change), which can cause damage to connected devices.
Material used:
The reducers are made of brass and are suitable for drinking water.
Technical specifications:
- Connection diameter 1''
- Maximum inlet pressure - 16 bar
- Maximum temperature - 30°C
- Output pressure adjustment range - 1 - 6 bar
- Nominal volumetric flow - DN25 = 3.6 m3/h
- Factory setting - 3 bars
- Pressure gauge connection - G 1/4
Additional parameters
Category: | Accessories for water filters |
---|---|
According to usage: | Reducing valve |
