Water Softener OP 125-700
Code: 4214 4215 4216 4217 4218 4219 Choose variantRelated products
Product detailed description
High-performance softener with a flow rate of up to 21 m³/h.
Now with a fully programmable control unit Autotrol Magnum 762.
Technical data:
Control unit: GE Autotrol MAGNUM LOGIX 762
Control head: volumetric (capacity)
Device programming: fully programmable
Maximum operating pressure: 1.72 - 6.9 bar
Inlet and outlet connections: stainless steel 1 ½" or 2", external thread
Drain connection: stainless steel 1 ½", external thread
Working temperatures: 1–36 °C
Built-in water meter
Built-in flow meter
Safety overflow
Electrical voltage: 230V/50 Hz
Power consumption: 5 W
Salt tank color: white
Filtration media: ion exchange resin
Ion exchange tank: glass fibers
The product is certified and designed for contact with drinking water.
Extended warranty of 3 years.
- A pre-filter for mechanical impurities must be installed before each softener.
- It is necessary to have a drain connection nearby, where the sedimented calcium, as well as iron and manganese from the filtration, is discharged.
| Name | Tank diameter (mm) | Height (mm) |
Salt tank diameter (mm) |
Salt tank (liters) | Ion exchange tank (") |
| OP 125 | 410 | 1918 | 723 | 340 | 16x65 |
| OP 180 | 464 | 1940 | 723 | 18x65 | |
| OP 225 | 540 | 1890 | 833 | 460 | 21x62 |
| OP 300 | 615 | 2170 | 833 | 460 | 24x72 |
| OP 500 | 767 | 2160 | 973 | 670 | 30x72 |
| OP 700 | 920 | 2235 | 1123 | 920 | 36x72 |
| Name | Connection | Amount of media (liters) |
Salt consumption (kg/1 regeneration) |
Nominal flow (m³/h) * |
Maximum flow (m³/h) ** |
| OP 125 | 1 ½" | 125 | 15 | 3.8 | 4.5 |
| OP 180 | 1 ½" | 180 | 22 | 5.4 | 7.2 |
| OP 225 | 1 ½" | 225 | 27 | 6.8 | 9.0 |
| OP 300 | 2" | 300 | 36 | 9.0 | 12.0 |
| OP 500 | 2" | 500 | 60 | 15.0 | 20.0 |
| OP 700 | 2" | 700 | 84 | 21.0 | 21.0 |
* Nominal flow - flow for continuous filter operation. Filtration efficiency is not reduced and remains constant.
** Maximum flow - flow for peak filter operation. Filtration efficiency does not decrease for a maximum of 5 minutes.
After 5 minutes of operation, the filtration efficiency very slowly begins to decrease.
Transport of the filtration device
We recommend sending the device on a pallet to avoid damage during transport. If you will also purchase regeneration salt together with the filtration device, add the pallet to your cart together with the salt.
Installation and servicing of the device
Installation and transportation will be provided by our own service technicians (we have 14 authorized service technicians throughout the Czech Republic and Slovakia). If interested, we would be happy to create a price quote for you. The installation price depends on the complexity and the materials used (connection hoses, valves, etc.). If you are interested in installation, please inform us in the note in the cart ("Enter a note for the seller").
Service replacements are recommended to be performed regularly once a year. The price for a service replacement is 1,990 CZK + travel costs, which are charged at a flat rate of 590 CZK (990 CZK for Prague and Brno) when the technician's trip is combined with additional installations or service work along the way.
Additional parameters
| Category: | Water Softeners |
|---|---|
| According to the connection: | On the water supply line |
| According to the type of filter: | For hard water, For water from a well |
| According to the variant of water treatment: | Economic option |
| According to usage: | For industry |
| By type: | Katexové |
| Product type for water treatment: | Water Softeners |
